Model: WCE55US0HB
30-inch Electric Ceramic Glass Cooktop with Dual Radiant Element
Send Email
Print

Product Description

Cook all your family’s favorites with an easy-to-clean cooktop designed to make the most of your mealtime routine. Get added flexibility when installing with 30 & 40 amp compatibility, or while cooking with the FlexHeat™ Dual Radiant Element. When dinner’s done, a ceramic glass cooktop makes it easy to wipe away messes.

White Stainless Steel Black
Color: Black

Model: WCE55US0HB
30-inch Electric Ceramic Glass Cooktop with Dual Radiant Element
Color: Black

Product Description

Cook all your family’s favorites with an easy-to-clean cooktop designed to make the most of your mealtime routine. Get added flexibility when installing with 30 & 40 amp compatibility, or while cooking with the FlexHeat™ Dual Radiant Element. When dinner’s done, a ceramic glass cooktop makes it easy to wipe away messes.

Features
FlexHeat™ Dual Radiant Element
Get two elements in one with a 6" inner ring that's great for smaller pots and pans and a 10" expandable outer ring that makes room for larger cookware.more

FlexHeat™ Dual Radiant Element

Get two elements in one with a 6" inner ring that's great for smaller pots and pans and a 10" expandable outer ring that makes room for larger cookware.

x
Easy-Wipe Ceramic Glass Cooktop
Wiping up spills is simple with the easy-to-clean cooktop.more

Easy-Wipe Ceramic Glass Cooktop

Wiping up spills is simple with the easy-to-clean cooktop.

x
30 & 40 Amp Installation
Properly install with either a 30 or 40 amp hookup, so there's no need to rewire.more

30 & 40 Amp Installation

Properly install with either a 30 or 40 amp hookup, so there's no need to rewire.

x
Hot Surface Indicator Light
See when the cooktop's still hot to the touch, even after it's been turned off, with a light that lets you know.more

Hot Surface Indicator Light

See when the cooktop's still hot to the touch, even after it's been turned off, with a light that lets you know.

x
Wall Oven Compatible
Install this cooktop to work with a wall oven or on its own for more flexibility.more

Wall Oven Compatible

Install this cooktop to work with a wall oven or on its own for more flexibility.

x
8" Extra Element
Cook small dishes like sides and sauces on the 8" Extra Element.more

8" Extra Element

Cook small dishes like sides and sauces on the 8" Extra Element.

x
6" Extra Element
Cook small dishes like sides and sauces on the 6" Extra Element.more

6" Extra Element

Cook small dishes like sides and sauces on the 6" Extra Element.

x
ADA compliant
This cooktop meets the Standards for Accessible Design specified by the Americans with Disabilities Act to provide equal access to all.more

ADA compliant

This cooktop meets the Standards for Accessible Design specified by the Americans with Disabilities Act to provide equal access to all.

x
Energy Star
ENERGY STAR® Certified models exceed government standards to help save money on your utility bills.more

Energy Star

ENERGY STAR® Certified models exceed government standards to help save money on your utility bills.

x
Specifications
Certifications
ADA Compliant ADA Height and Operation Compliant , ADA Height and Operation Compliant
Prop 65 Prop 65 warning CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Energy Star® Qualified ENERGY STAR® Qualified
ADA Compliant
ADA Height and Operation Compliant , ADA Height and Operation Compliant
Prop 65
Prop 65 warning CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Energy Star® Qualified
ENERGY STAR® Qualified
Details
Cooktop Configuration All Burners , All Burners
Fuel Type Electric , Electric
Installs Over Built-In Oven Yes
LP Convertible No , No
Power Outage Compatible No , No
Cooktop Type Standard
Cooktop Surface Color Black
Cooktop Surface Material Glass
Digital Display No , No
Cooktop Configuration
All Burners , All Burners
Fuel Type
Electric , Electric
Installs Over Built-In Oven
Yes
LP Convertible
No , No
Power Outage Compatible
No , No
Cooktop Type
Standard
Cooktop Surface Color
Black
Cooktop Surface Material
Glass
Digital Display
No , No
Element/Burner Details
Cooktop Element Style Radiant , Radiant
Cooktop Type Standard , Standard
Left Front Element-Burner Power 1,200W , 1,200W
Left Front Element-Burner Size 6in. , 6in.
Left Front Element-Burner Type Standard , Standard
Left Rear Element-Burner Power 1,800W , 1,800W
Left Rear Element-Burner Size 8in. , 8in.
Left Rear Element-Burner Type Standard , Standard
Number of Cooking Element-Burners 4 , 4
Power Boost No , No
Right Front Element-Burner Power 2500W/1800W , 2500W/1800W
Right Front Element-Burner Size 10in./6in. , 10in./6in.
Right Rear Element-Burner Size 6in. , 6in.
Right Front Element-Burner Type Dual , Dual
Right Rear Element-Burner Power 1,200W , 1,200W
Right Rear Element-Burner Type Standard , Standard
Automatic Pan Detection No , No
Cooktop Element Style
Radiant , Radiant
Cooktop Type
Standard , Standard
Left Front Element-Burner Power
1,200W , 1,200W
Left Front Element-Burner Size
6in. , 6in.
Left Front Element-Burner Type
Standard , Standard
Left Rear Element-Burner Power
1,800W , 1,800W
Left Rear Element-Burner Size
8in. , 8in.
Left Rear Element-Burner Type
Standard , Standard
Number of Cooking Element-Burners
4 , 4
Power Boost
No , No
Right Front Element-Burner Power
2500W/1800W , 2500W/1800W
Right Front Element-Burner Size
10in./6in. , 10in./6in.
Right Rear Element-Burner Size
6in. , 6in.
Right Front Element-Burner Type
Dual , Dual
Right Rear Element-Burner Power
1,200W , 1,200W
Right Rear Element-Burner Type
Standard , Standard
Automatic Pan Detection
No , No
Exterior Details
Knob Color Black , Black
Knob Type Dishwasher-Safe Plastic , Dishwasher-Safe Plastic
Knob Color
Black , Black
Knob Type
Dishwasher-Safe Plastic , Dishwasher-Safe Plastic
Dimensions
Cutout Depth 20.375 in, 20.375 in
Cutout Depth Max 20.563 in, 20.563 in
Cutout Depth Min 20.375 in, 20.375 in
Cutout Width 29.063 in, 29.063 in
Cutout Width Max 29.563 in, 29.563 in
Depth 22.875 in, 22.875 in
Cutout Width Min 29.063 in
Gross Weight 42 lbs, 46 lbs
Height 5.25 in, 5.25 in
Net Weight 37 lbs, 41 lbs
Width 30.8125 in, 30.8125 in
Common Size 30 in, 30 in
Maximum Height 5.25 in, 5.25 in
Cutout Depth
20.375 in, 20.375 in
Cutout Depth Max
20.563 in, 20.563 in
Cutout Depth Min
20.375 in, 20.375 in
Cutout Width
29.063 in, 29.063 in
Cutout Width Max
29.563 in, 29.563 in
Depth
22.875 in, 22.875 in
Cutout Width Min
29.063 in
Gross Weight
42 lbs, 46 lbs
Height
5.25 in, 5.25 in
Net Weight
37 lbs, 41 lbs
Width
30.8125 in, 30.8125 in
Common Size
30 in, 30 in
Maximum Height
5.25 in, 5.25 in
Controls
Control Location Right , Right
Control Type Knobs , Knobs
Control Location
Right , Right
Control Type
Knobs , Knobs
Ventilation Details
Downdraft Vent No , No
Downdraft Vent
No , No
Features
Cooktop Features ADA Compliant
Cooktop Features
ADA Compliant
Cooktop Details
Cooktop Surface Color Black , Black
Cooktop Surface Material Glass , Glass
Digital Display No
Griddle Included N/A , N/A
Heating Element On Indicator Light Yes , Yes
Hot Surface Indicator Light Yes , Yes
Combination Match with Oven WOES3027L , WOES3030L , WOES5027L , WOES5030L , WOES5930L , WOES7027P , WOES7030P , WOS11EM4 , WOS31ES0 , WOS31ES7 , WOS51EC0 , WOS51EC7 , WOS51ES4 , WOS52EM4 , WOS72EC0 , WOS72EC7 , WOS92EC0 , WOS92EC7 , WOS97EC0 , WOS97ES0 , WOSA2EC0 , WOES3027L , WOES3030L , WOES5027L , WOES5030L , WOES5930L , WOES7027P , WOES7030P , WOS11EM4 , WOS31ES0 , WOS31ES7 , WOS51EC0 , WOS51EC7 , WOS51ES4 , WOS52EM4 , WOS72EC0 , WOS72EC7 , WOS92EC0 , WOS92EC7 , WOS97EC0 , WOS97ES0 , WOSA2EC0
Installs Over Built-In Oven Yes , Yes
Cooktop Surface Color
Black , Black
Cooktop Surface Material
Glass , Glass
Digital Display
No
Griddle Included
N/A , N/A
Heating Element On Indicator Light
Yes , Yes
Hot Surface Indicator Light
Yes , Yes
Combination Match with Oven
WOES3027L , WOES3030L , WOES5027L , WOES5030L , WOES5930L , WOES7027P , WOES7030P , WOS11EM4 , WOS31ES0 , WOS31ES7 , WOS51EC0 , WOS51EC7 , WOS51ES4 , WOS52EM4 , WOS72EC0 , WOS72EC7 , WOS92EC0 , WOS92EC7 , WOS97EC0 , WOS97ES0 , WOSA2EC0 , WOES3027L , WOES3030L , WOES5027L , WOES5030L , WOES5930L , WOES7027P , WOES7030P , WOS11EM4 , WOS31ES0 , WOS31ES7 , WOS51EC0 , WOS51EC7 , WOS51ES4 , WOS52EM4 , WOS72EC0 , WOS72EC7 , WOS92EC0 , WOS92EC7 , WOS97EC0 , WOS97ES0 , WOSA2EC0
Installs Over Built-In Oven
Yes , Yes
Electrical Requirements
208V Compatible Yes , Yes
Power Cord Included No , No
Amps 30 , 30
Hz 60
Volts 240
208V Compatible
Yes , Yes
Power Cord Included
No , No
Amps
30 , 30
Hz
60
Volts
240
Documents
UPC Listing
Model "WCE55US0HB" UPC: 883049472430
Model "WCE55US0HS" UPC: 883049472782
Model "WCE55US0HW" UPC: 8.83049E+11
Model "WCE55US0HB"
UPC: 883049472430
Model "WCE55US0HS"
UPC: 883049472782
Model "WCE55US0HW"
UPC: 8.83049E+11
