Model: MER7700LZ
Electric Range with Air Fryer and Basket - 5.3 cu. ft.
Send Email
Print
Product Description

This Maytag® electric range with air fryer is here to cook the foods you want, when you want them. Use the included oven air fry basket to air fry your favorites and then toss it in the dishwasher for easy cleanup. Don’t worry about rotating your dishes while you cook—fan convection cooking circulates hot air around your oven so you can cook your whole meal at once. Use the warming center on your range with air fry to keep your finished food warm while the rest of your food cooks. When you’re done cooking, high temp self clean will fight the toughest baked-on foods to keep your electric range with air fryer looking clean.

Color: Fingerprint Resistant Stainless Steel

Model: MER7700LZ
Electric Range with Air Fryer and Basket - 5.3 cu. ft.
Color: Fingerprint Resistant Stainless Steel

Product Description

This Maytag® electric range with air fryer is here to cook the foods you want, when you want them. Use the included oven air fry basket to air fry your favorites and then toss it in the dishwasher for easy cleanup. Don’t worry about rotating your dishes while you cook—fan convection cooking circulates hot air around your oven so you can cook your whole meal at once. Use the warming center on your range with air fry to keep your finished food warm while the rest of your food cooks. When you’re done cooking, high temp self clean will fight the toughest baked-on foods to keep your electric range with air fryer looking clean.

Features
Air Fry
Air Fry allows you to make your favorite fried foods with a crispy-on-the-outside, juicy-on-the-inside taste using little to no additional oil.more
Dishwasher-safe Air Fry basket
Just toss your favorite foods into the 13" x 18" stainless steel basket included in your range for crisp results, and after eating, toss the basket into the dishwasher for easy cleanup.more
Fan convection cooking
With two heating elements, fan convection circulates hot air around the oven so you can cook the whole meal at once without having to rotate your dishes for all around baking.more
Warming center
A warming center adds a dedicated cooktop zone to keep your finished food warm while you use the other elements to get the rest of your meal cooked.more
High Temp Self Clean
Fight the toughest baked-in foods in your oven with this high-heat, self-cleaning technology.more
5 Elements
With an extra element, you have the flexibility to prepare your meal without juggling pots and pans, getting you to dinner fast.more
Delay Bake setting
With the Delay Bake setting, just place your dishes in the oven and program when you want the baking to begin so your food is ready when you are.more
Hidden Bake Element
The hidden bake element is sealed under the oven floor to protect it from spills and drips.more
Fingerprint resistant stainless finish
The easy-to-clean fingerprint resistant stainless finish keeps your oven looking as good on the outside as it works on the inside.more
9"/6" Dual-Choice™ Element
The 9"/6" Dual-Choice™ element matches the heat to the pan you’re using so you can cook your meal the way you want.more
Ceramic Glass cooktop
The smooth ceramic glass cooktop lets you easily wipe spills from all the delicious meals you‘ll prepare.more
5.3 Cu. Ft. Capacity
Cook the whole meal with plenty of space in this 5.3 cu. ft. capacity electric range.more
Proudly assembled in Tulsa, Oklahoma, U.S.A.
We take pride in building strong, reliable appliances for your home. These ranges are proudly assembled by hard-working employees in Tulsa, Oklahoma.more
Designed to last
The ceramic glass cooktop and sturdy door hinges on this Maytag® air fry electric range are built for dependability, while fingerprint resistant stainless finish helps make cleaning easier.more
An American company for over 100 years
Whirlpool Corporation started in 1911 in Benton Harbor, Michigan. Today we are a global home appliance business selling products around the world. We are proud of our American heritage and ingenuity that have driven innovation for over 100 years.more
10-Year Limited Parts Warranty
With a 10-year limited parts warranty on the glass cooktop, elements and cavity, we built these ranges tough enough to keep cooking for years.more
Specifications
Certifications
ADA Compliant No
CUL Yes
UL Yes
Prop 65 Prop 65 warning CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADA Compliant
No
CUL
Yes
UL
Yes
Prop 65
Prop 65 warning CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Oven Cavity Details
Number of Oven Racks 2
Convection Functions No
Oven Rack Type Standard (Both)
Broiler Location Top Center
Oven Cleaning Type Adjustable Self Cleaning
Door Removable Yes
Number of Oven Lights 1
Convection Element Type None
Oven Light Type Incandescent
Interior Color Black
Number of Rack Guides 5
Hidden Bake Element Yes
Oven Cooking System Convection
Broiler Element Power 3,400 W
Bake Element Power 2,400 W
Automatic Convection Conversion Temperature Adjust No
Oven Light Switch Location Top of Console
Number of Oven Racks
2
Convection Functions
No
Oven Rack Type
Standard (Both)
Broiler Location
Top Center
Oven Cleaning Type
Adjustable Self Cleaning
Door Removable
Yes
Number of Oven Lights
1
Convection Element Type
None
Oven Light Type
Incandescent
Interior Color
Black
Number of Rack Guides
5
Hidden Bake Element
Yes
Oven Cooking System
Convection
Broiler Element Power
3,400 W
Bake Element Power
2,400 W
Automatic Convection Conversion Temperature Adjust
No
Oven Light Switch Location
Top of Console
Details
Cooktop Configuration All Burners
Fuel Type Electric
Oven Automatic Shut-Off No
Power On Indicator Light Yes
Power Outage Compatible No
Range Type Freestanding
Oven Cleaning Type Adjustable Self Cleaning
Cooktop Surface Color Black
Handle Color Stainless Steel
Handle Material Metal
Oven Selections Air Fry , Audible Signal , Bake , Broil , Cancel/Off , Clock , Control Lock , Cook Time Indicator , Delay Start , Keep Warm/Warm Hold , Sabbath Mode , Start Time , Timer
Cooktop Configuration
All Burners
Fuel Type
Electric
Oven Automatic Shut-Off
No
Power On Indicator Light
Yes
Power Outage Compatible
No
Range Type
Freestanding
Oven Cleaning Type
Adjustable Self Cleaning
Cooktop Surface Color
Black
Handle Color
Stainless Steel
Handle Material
Metal
Oven Selections
Air Fry , Audible Signal , Bake , Broil , Cancel/Off , Clock , Control Lock , Cook Time Indicator , Delay Start , Keep Warm/Warm Hold , Sabbath Mode , Start Time , Timer
Element/Burner Details
Center Front Element-Burner Power 100W
Center Front Element-Burner Size 6in.
Center Front Element-Burner Type Warming
Cooktop Element Style Radiant
Left Front Element-Burner Power 3,000W
Left Front Element-Burner Size 9in./6in.
Left Front Element-Burner Type Dual
Left Rear Element-Burner Power 1,200W
Left Rear Element-Burner Size 6in.
Left Rear Element-Burner Type Standard
Right Front Element-Burner Power 3,000W
Right Front Element-Burner Size 9in./6in.
Right Rear Element-Burner Size 6in.
Right Front Element-Burner Type Dual
Right Rear Element-Burner Power 1,200W
Right Rear Element-Burner Type Standard
Center Front Element-Burner Power
100W
Center Front Element-Burner Size
6in.
Center Front Element-Burner Type
Warming
Cooktop Element Style
Radiant
Left Front Element-Burner Power
3,000W
Left Front Element-Burner Size
9in./6in.
Left Front Element-Burner Type
Dual
Left Rear Element-Burner Power
1,200W
Left Rear Element-Burner Size
6in.
Left Rear Element-Burner Type
Standard
Right Front Element-Burner Power
3,000W
Right Front Element-Burner Size
9in./6in.
Right Rear Element-Burner Size
6in.
Right Front Element-Burner Type
Dual
Right Rear Element-Burner Power
1,200W
Right Rear Element-Burner Type
Standard
Exterior Details
Door Type Metal & Glass
Handle Material Metal
Handle Color Stainless Steel
Handle Type Reach Through Handle
Oven Control Knob Color Stainless Steel
Oven Control Knob Type Plastic
Oven Control Location Backguard
Oven Control Type Electronic Touch
Oven Window Size Large
Display Color Blue
Door Type
Metal & Glass
Handle Material
Metal
Handle Color
Stainless Steel
Handle Type
Reach Through Handle
Oven Control Knob Color
Stainless Steel
Oven Control Knob Type
Plastic
Oven Control Location
Backguard
Oven Control Type
Electronic Touch
Oven Window Size
Large
Display Color
Blue
Dimensions
Cutout Depth 24 in
Cutout Height 36 in
Cutout Width 30 in
Depth 27-3/4 in
Depth Closed Excluding Handles 25-313/1000 in
Depth Closed Including Handles 28 in
Depth With Door Open 90 Degree 46-86/125 in
Gross Weight 160 lbs
Height 47-7/8 in
Net Weight 141 lbs
Oven Interior Height 18-1/8 in
Oven Interior Depth 18-1/2 in
Oven Interior Width 24-1/2 in
Width 29-7/8 in
Common Size 30 in
Maximum Height 47-7/8 in
Minimum Height 46-7/8 in
Cutout Depth
24 in
Cutout Height
36 in
Cutout Width
30 in
Depth
27-3/4 in
Depth Closed Excluding Handles
25-313/1000 in
Depth Closed Including Handles
28 in
Depth With Door Open 90 Degree
46-86/125 in
Gross Weight
160 lbs
Height
47-7/8 in
Net Weight
141 lbs
Oven Interior Height
18-1/8 in
Oven Interior Depth
18-1/2 in
Oven Interior Width
24-1/2 in
Width
29-7/8 in
Common Size
30 in
Maximum Height
47-7/8 in
Minimum Height
46-7/8 in
Controls
Display Color Blue
Electronic Display Type LED
Display Color
Blue
Electronic Display Type
LED
Smart Compatibility
Connectivity No
Works With No
Connectivity
No
Works With
No
Dimensions
Gross Weight 160.000 lbs
Gross Weight
160.000 lbs
Cooktop Details
Cooktop Control Knob Color Stainless Steel
Cooktop Control Location Backguard
Cooktop Control Knob Type Plastic
Cooktop Control Type Knobs
Cooktop Surface Color Black
Cooktop Surface Material Glass
Heating Element On Indicator Light Yes
Hot Surface Indicator Light Yes
Cooktop Control Knob Color
Stainless Steel
Cooktop Control Location
Backguard
Cooktop Control Knob Type
Plastic
Cooktop Control Type
Knobs
Cooktop Surface Color
Black
Cooktop Surface Material
Glass
Heating Element On Indicator Light
Yes
Hot Surface Indicator Light
Yes
Electrical Requirements
Power Cord Included No
Power Cord Included
No
Documents
UPC Listing
Model "MER7700LZ" UPC: 883049624556
Model "MER7700LZ"
UPC: 883049624556
